SITOP COMPACT

The slim power supply unit for control boxes

Thanks to the extremely space-saving slim design, the new power supply series for the lower performance range is especially suited to distributed applications in control boxes or in small control cabinets. The switched-mode power supplies are characterized by their low power loss over the entire load range.

Power loss is extremely low even during no-load operation, which is why they are ideal, for example, for supplying machinery and equipment that are often in stand-by mode. The SITOP PSU100C switched-mode power supplies have a wide input voltage range for AC and DC networks, with plug-in terminals allowing a simple electrical connection.

Essential product features

  • 24V DC/0.6 A, 1.3 A, 2.5A, and 4 A and 12V DC/2.0 A and 6.5A
  • Small mounting surface thanks to its slim design
  • Wide input voltage range from 85 V to 264 V AC or 100 VDC to 300 V DC
  • High efficiency over the entire load range. Up to 28 % energy savings compared to similar units
  • Low energy consumption during no-load or standby operation. Up to 53 % energy savings possible
  • Adjustable output voltage
  • Green LED for “Output voltage o. k.”
  • Plug-in terminals
  • Temperature range from -20 °C to +70 °C
  • Comprehensive certification, e. g. ATEX
